•Typical applications include creating water fountains, pumping water garden features and conducting aeration or filtration for aquarium and fish pond.
•The DC brushless water pump kit consists of a DC brushless water pump and a solar panel module.
•Solar energized, maintenace free, cost free and easy to install.
•No failure-prone carbon brush or shaft seal so that a robust and long service life could be expected.
•Ceramic shaft, runs steadily and quietly.
•Designed and manufactured to have high power efficiency.
•Cost-effectiveness, competitive price.
Item No. | SP20-501210A (Old item No.: SBL1502) | ||||||||
Description | Solar brushless pump kit | ||||||||
Category | Solar pump kit | ||||||||
| |||||||||
Product Summary | |||||||||
Solar panel | Solar panel item | GSP20-36 | |||||||
Peak power | 20W | ||||||||
Peak power voltage | 17.28V | ||||||||
Peak power current | 1.157A | ||||||||
Pump | Pump item | BP501210A | |||||||
Maximum pump head | 2.1m (6.9ft) | ||||||||
Maximum flow rate | 1360L/H (359.3GPH) | ||||||||
Cable length | 5m (16.4ft) | ||||||||
nozzle item | NA03 | ||||||||
Flow adjustable | yes | ||||||||
Dry run protection | no | ||||||||
Individual box size | 53X36X24cm | ||||||||
Individual box G.W | 4kg | ||||||||
Master carton size | 55X51X39cm | ||||||||
Quantity per carton | 2pcs | ||||||||
Master carton G.W | 9kg | ||||||||
Quantity per 20 container | 960pcs | ||||||||
Quantity per 40 container | 2000pcs | ||||||||
Warranty | 3years | ||||||||
| |||||||||
Litres per hour - At various pumping heights (Head) | |||||||||
Operating | @ 0m | @0.5m | @0.75m | @1.0m | @1.5m | @2.0m | @2.5m | @3.0m | Max height |
18V | 1350 | 1070 | 840 | 755 | 420 | 60 | 0 |
| 2.1m |
| |||||||||
Pump Curve | |||||||||
| |||||||||
