Models | Outlet DN (mm) | Inlet DN (mm) | Capacity (m3/h) | Head (m) | Speed (r/min) | Max power (KW) |
25HS-B | 25mm(1'') | 1.5'' | 12.6~28.8 | 6~68 | 1200~3800 | 15 |
25HHS-C | 25mm(1'') | 1.5'' | 16.2~34.2 | 25~92 | 1400~2200 | 30 |
40HS-B | 40mm(1.5'') | 2‘’ | 32.4~72 | 6~58 | 1200~3200 | 15 |
50HS-C | 50mm(2'') | 3'' | 39.6~86.4 | 12~64 | 1300~2700 | 30 |
50HHS-D | 50mm(2'') | 3'' | 68.4~136.8 | 25~87 | 850~1400 | 60 |
75HS-C | 75mm(3'') | 4'' | 86.4~198 | 9~52 | 1000~2200 | 30 |
75HHS-E | 75mm(3'') | 4'' | 126~252 | 12~97 | 600~1400 | 120 |
100HS-D | 100mm(4'') | 6'' | 162~360 | 12~56 | 800~1550 | 60 |
100HHS-E | 100mm(4'') | 6'' | 324~720 | 30~118 | 600~1000 | 560 |
150HS-E | 150mm(6'') | 8'' | 360~828 | 10~61 | 500~1140 | 300 |
200MS-E | 200mm(8'') | 10'' | 666~1440 | 14~60 | 600~1100 | 120 |
200HS-ST | 200mm(8'') | 10'' | 612~1368 | 11~61 | 400~850 | 560 |
250HS-ST | 250mm(10'') | 12'' | 936~1980 | 7~68 | 300~800 | 560 |
300HS-TU | 300mm(12'') | 14'' | 1260~2772 | 13~63 | 300~600 | 560 |
350HS-TU | 350mm(14'') | 16'' | 1368~3060 | 11~63 | 250~550 | 1200 |
450HS-TU | 450mm(18'') | 20'' | 2520~5400 | 13~57 | 200~400 | 1200 |
